Unrecorded Utility Crossing Under a Street — Parallel GPR Profiles at 350 MHz

Unrecorded Utility Crossing Under a Street — Parallel GPR Profiles at 350 MHz

Description

Utility survey on a street, acquired with a GSSI UtilityScan 350 MHz HyperStacking antenna: 9 parallel profiles spaced 1 m apart, crossing the alignment of a planned trench.

The survey revealed utilities that do not appear on the record drawings, crossing the street diagonally right where the trench was to be dug. The dataset also shows shallow changes in the road structure — surface layer variations and backfill from earlier works — which produce reflections easily confused with utilities by an untrained eye.

This combination makes it a realistic training case for utility detection before excavation: locating the crossings, following them from one profile to the next, and telling buried services apart from ground structure. Raw unprocessed files.

géodétection de réseaux, utility detection, détection de réseaux enterrés, underground utility survey, réseaux non répertoriés, unrecorded utilities, réseaux absents des plans, missing from record drawings, plan de récolement, record drawings, travaux réseaux, utility works, tranchée, trench, avant terrassement, pre-excavation survey, prévention des endommagements, damage prevention, traversée de voirie, street crossing, réseau en diagonale, diagonal utility, profils parallèles, parallel profiles, structure de chaussée, road structure, remblai, backfill, HyperStacking

Information

ApplicationUnderground Utilities
GSSI antennaUtilityScan DF
Frequency300/800 MHz
FormatDZT
Size44 Mo
ContributorMDSLab
Added on2026-08-13

Cite this dataset

APA

MDS - Le Matériel de Sondage - GPRbase (2026). Unrecorded Utility Crossing Under a Street — Parallel GPR Profiles at 350 MHz [Data set]. GPRbase. GSSI, UtilityScan DF, 300/800 MHz. https://www.gprbase.com/en/dataset/ds024-unrecorded-utility-crossing-under-a-street-parallel-gpr/

BibTeX

@misc{gprbase_ds024,
  author       = {MDS - Le Matériel de Sondage - GPRbase},
  title        = {Unrecorded Utility Crossing Under a Street — Parallel GPR Profiles at 350 MHz},
  year         = {2026},
  publisher    = {GPRbase},
  howpublished = {\url{https://www.gprbase.com/en/dataset/ds024-unrecorded-utility-crossing-under-a-street-parallel-gpr/}},
  note         = {GSSI, UtilityScan DF, 300/800 MHz. Licensed under CC BY-NC-SA 4.0},
}
