T-Shaped Retaining Wall: Variable Thickness from a Vertical then Horizontal GPR Profile

T-Shaped Retaining Wall: Variable Thickness from a Vertical then Horizontal GPR Profile

Description

T-shaped retaining wall surveyed with a GSSI FLEX NX antenna. A single profile, run first vertically up the stem, then horizontally, without interrupting the acquisition.

The concrete-air interface at the back face stands out clearly on the radargram. Its depth gives the stem thickness at any point, and the stem of a T-wall is not of constant thickness: it thickens towards the base to resist earth pressure. The back-wall reflector therefore forms an oblique line rather than one parallel to the surface.

The change of direction mid-profile produces a visible break in the section. Recognising it is part of the exercise: it is a reminder that the distance axis follows the antenna path, not the geometry of the structure.

Raw unprocessed files.

mur de soutènement, retaining wall, mur en T, T-wall, voile, stem, semelle, footing, épaisseur variable, variable thickness, fruit du voile, wall taper, poussée des terres, earth pressure, interface béton-air, concrete-air interface, réflexion de fond, back-wall reflection, réflecteur oblique, oblique reflector, mesure d'épaisseur, thickness measurement, profil vertical, vertical profile, changement d'orientation, direction change, ouvrage de soutènement, earth-retaining structure, génie civil, civil engineering

Information

ApplicationConcrete / Civil Eng.
GSSI antennaFLEX NX
Frequency2500 MHz
FormatDZT
Size8,3 MB
Files1
Channels2
GPS filesNot available
ContributorMDSLab
Added on2026-08-27
Ground truth Partial

Cite this dataset

APA

MDS - Le Matériel de Sondage - GPRbase (2026). T-Shaped Retaining Wall: Variable Thickness from a Vertical then Horizontal GPR Profile [Data set]. GPRbase. GSSI, FLEX NX, 2500 MHz. https://www.gprbase.com/en/dataset/ds033-t-shaped-retaining-wall-variable-thickness-from-a-vertical/

BibTeX

@misc{gprbase_ds033,
  author       = {MDS - Le Matériel de Sondage - GPRbase},
  title        = {T-Shaped Retaining Wall: Variable Thickness from a Vertical then Horizontal GPR Profile},
  year         = {2026},
  publisher    = {GPRbase},
  howpublished = {\url{https://www.gprbase.com/en/dataset/ds033-t-shaped-retaining-wall-variable-thickness-from-a-vertical/}},
  note         = {GSSI, FLEX NX, 2500 MHz. Licensed under CC BY-NC-SA 4.0},
}
